Kenwood

XR-W1204

SKU 210000003261
$239.99
$239.99

XR-W1204(4Ω)

12" Oversized Subwoofer


GENERAL FEATURES

  • Peak Power: 2000 W
  • RMS Power: 400 W
  • Frequency Response: 32Hz-300Hz
  • Impedance: 4 Ω
  • Mounting Depth: 5-5/8inch

eXcelon SPEAKERS

Speakers may be the most important piece of the sound quality puzzle. eXcelon speakers employ oversized drivers to enhance low-end range and large tweeters that improve mid- to high-range transitions, ideal for clear and dynamic vocals. Oversized woofers provide quick response and offer stable and powerful bass that remains true to the original recording.

Test and Measurement

Speaker and subwoofer development requires a diligent testing process including an anechoic chamber, power testing facility and the most advanced desktop applications for design and simulation. These high standards allow KENWOOD eXcelon speakers to deliver their expected performance and have long term reliability so your music can be enjoyed for many years.

Cross Section Unit

Oversized Diaphragm
Low frequency output is increased because of a larger cone size. The cutout diameter has remained the same making this feature of the new XR woofers ideal for most vehicles where space is a premium. The XR woofers are ideal for a small sealed box.
* RECOMMENDED SEALED BOX VOLUME: 0.88 cft

Reinforcing Ribs (Cone)
The newly designed cone features ribbing that adds strength to the cone and minimizes distortion.

Strong Magnetic Circuit
Our engineers designed a strong magnetic circuit with the purpose of reproducing deep low frequencies. Their efforts employed a large magnet and optimized yoke.

Stress-free Spider
By adopting a "Stress-free Spider" and a "Thermal Efficient System" the mechanical and thermal durability has been improved dramatically delivering smooth and strong bass sound with long lasting reliability. SPECIFICATIONS:

XR-W1204
Woofer Size Over sized 30cm Over sized 12in
Diaphragm PP Cone Gray
Surround Rubber Black
Basket Steel Black
Magnet Ferrite φ155xt16x2pcs
DIMENSION Woofer (Unit) Width 12-13/16in
Height 12-13/16in
Cutout Diameter 11in
Depth 6-1/2in
Mounting Depth 5-5/8in
WEIGHT Woofer (pc.) 15.2lb(6.9kg)
Gross Weight >17.6lb(8.0kg)
NOMINAL IMPEDANCE 4ohms
POWER HANDLING Peak Power 2000W
RMS Power (CEA SPEC) >400W
SENSITIVITY 83dB / W at 1m
FREQUENCY RESPONSE 32Hz-300Hz
ACCESSORY Screw sets φ4*35 *8pcs
Cushion *1pc
Warranty Card *1pc
SPECIAL FEATURE Dual ventilation system
Over sized Cone
Stress-Free Damper
8AWG Push Terminal
Rubber Magnet Cover
